HD60FE655 OEM Carrier Blower Motor | 3.7 HP | 208-230/460V

HD60FE655 OEM Carrier Blower Motor | 3.7 HP | 208-230/460V

HD60FE655 OEM Carrier Blower Motor | 3.7 HP | 208-230/460V

$3,200.00

$3,200.00

Product Information

Part Number: HD60FE655

Product Type: Commercial Blower Motor

Brand: Factory Authorized Parts

Specifications

Specification	Value
Horsepower	3.7 HP
Voltage	208-230 / 460 VAC
Phase	Three Phase
Frequency	50/60 Hz
Full Load Amps	10.2 / 4.8 A
Speed	1725 RPM
Rotation	Counter Clockwise (CCW)
Bearing Type	Ball Bearing
Frame	NEMA 56Z
Shaft Diameter	7/8"
Shaft Length	3-9/16"
Enclosure	Open
Duty	Continuous Duty
Country of Origin	Mexico
Weight	42.25 lbs (19.2 kg)

Common Causes of Blower Motor Failure

Blower motors typically fail because of one or more of the following:

Worn or seized bearings
Motor windings shorted or open
Water entering the motor
Overheating caused by restricted airflow
Dirty blower wheel increasing motor load
Failed capacitor (single-phase motors)
Incorrect supply voltage
Loose electrical connections
Excessive amp draw
Age and normal wear

Common Symptoms

A faulty blower motor may cause:

No airflow
Weak airflow
Blower will not start
Motor hums but won't turn
Breaker trips
Burning electrical smell
Grinding bearings
Loud vibration
Blower starts then shuts off
Motor overheats
Unit trips on high limit because of low airflow

Compatible Equipment

Carrier Fan Coils

40RM012510
40RM012610
40RM014510
40RUAA16AA6A
40RUQA12AA6A
40RUSA12AA6A
40RUSA14AA6A

Carrier Packaged Rooftop Units
